Wuxi Yaheng Geological Equipment Technical Co.,Ltd Show The Technology By Quality!
11 Years
| Ask Lasest Price | |
| Brand Name : | Yaheng |
| Certification : | ISO9001 |
| Price : | usd dollar 300~450 per piece |
| Payment Terms : | L/C, D/P, T/T, Western Union |
| Supply Ability : | 1000 piece per month |
| Delivery Time : | 5~8 days after payment |
Description:
UMX diamond bits have revolutionized mineral exploration. UMX bits drill faster, last longer, and perform in a wider range of drilling conditions and formations. The extended range and versatility of the UMX diamond bits means less tripping out rods and more core in the box.
1) certifacation Iso 9001:2008
2) with very small high quality synthetic diamonds mixed.
3) impregnated core bits are more economical to use than other bits.
4) can drill a broad range of geological formations from the softest to the hardest rock
5) widely used in all kinds of drillings for prospecting, water and electricity building and construction industry of road, railway, bridge and building taking out core to examine stake
Dimensions of Core Bits:
| "Q" series: | AQ, BQ, NQ, HQ, PQ/AQTK, BQTK, BQ3, NQ2, NQ3, NQTT, HQ3, HQTT, PQ3, PQTT |
| A-Gauge Core Bits: | AQ, AQ-RSG, AWG(AX), AWM, AWT, LTK48 |
| B-Gauge Core Bits: | BQ, BQ-RSG, BQ-2.400, BQ3, BWG(BX), BWM, BWT, LTK60, TBW |
| N-Gauge Core Bits: | NQ, NQ-RSG, NQ-3.032, NQ2, NQ2-RSG, NQ3/NQTT, NQ3-RSG, NQ3-3.032, NMLC, NWG(NX), NWM, NWT, TNW, |
| H-Gauge Core Bits: | HQ, HQ-RSG, HQ-3.830, HQ-3.895, HQ3/HQTT, HQ3-RSG, HQ3-3.895, HMLC, HWF-Long, HWF-Short, HWG(HX), HWT |
| P-Gauge Core Bits: | PQ, PQ3, PWF-Long, PWF-Short |
| S-Gauge Core Bits: | SWF-Long, SWF-Short |
| U-Gauge Core Bits: | UWF-Long, UWF-Short |
| Z-Gauge Core Bits: | ZWF-Long, ZWF-Short |
| T Series: | T36, T46, T56, T66, T76, T86, T101 |
| TT Series: | TT46, TT56, TT66, TT76, TT86, TT101 |
| T2 Series: | T2 46, T2 56, T2 66, T2 76, T2 86, T2 101 |
| TB Series Metric Core Bits: | TB36, TB46, TB56, TB66, TB76, TB86, TB101 |
| T6 Series Metric Core Bits: | T6-76, T6-86, T6-101, T6-116, T6-131, T6-146 |
| T6S Series Metric Core Bits: | T6S-76, T6S-86, T6S-101, T6S-116, T6S-131, T6S-146 |
| B Series(IS03552-1)Metric Core Bits: | B36, B46, B56, B66, B76, B86, B101, B116, B131, B146 |
| All other standard: | CDDA, DCDMA, Crealius, and ISO sizes. |
Notice:
To select the right bit for the job, assess the speed and power of your drill for the size and depths of the holes to be drilled and assess ground conditions such as rock type/formation and down-hole conditions.
Size:
bits are available in all standard drilling sizes. Also,
non-standard sized bits can be produced according to requirements
from clients.
Crown Height:
offers crown impreg depths of 9mm, 12mm, and 16mm .The taller crown
heights provide improved bit stability and reduced vibrations,
enhancing bit life and performance.
Waterways:
Various waterways are available for diamond impregnated bits.
Differing waterways allow for better flushing in various ground
conditions and drilling systems.
Matrix:
ROSCHEN impregnated bits matrices can be selected by our engineer according
to ground conditions at client's work site.
Threads:
standard Q threads as well as thread types required by clients are available.
ABOUT US:
Wuxi Yaheng Geological Equipment Technical Co.,Ltd is a professional diamond tools manufacturer in China.
We specialize manufacturing core drilling tools and diamond tools ,core drills ,core drill rods,wireline core drill parts ect.
Yaheng 's products are widely used in geological and mineral,metallurgy,mining and hydrology industries.
Yaheng's egineers are good at making research and development,and we also have a good sales team which is professional and active service.
|
|
